Affordable & Lightweight Formwork
Each Panel Height in 600mm
SP600 is similar to PERI’s DUO and GEOplast Universal Formwork System. It is very easy to use even for unskilled workers and is equipped with quick-install handles. With just a few panel sizes and accessories, walls, columns and floors can be formed efficiently.
Fast and Efficint Shuttering
No Cranes, Universal, Lightweight
Widely used in forming walls, corners, ring beams, foundations, basements, doors and windows, elevator shafts, swimming pools, floor slabs, beams, etc.
Technical Data
Material
ABS (Acrylonitrile-Butadiene-Styrene)
Sizes
Column Panels Width: 100-1200mm
Column Panels Height: 600mm
Wall Panels Width: 100-1200mm
Wall Panels Height: 600mm
Corner Panels Width: 100×50/200x200mm
Corner Panels Height: 200/250/600mm
Mini Formwork: 250x250x70/250x200x70200x200x70mm
Inner Angular Formwork: 200x200x200mm
Window /Door Corner Formwork:
200x100x50mm
Round Column: 300/350/400/450x750mm
Adjustable Column Formwork: 750x730x70mm
Column Panels Height: 600mm
Wall Panels Width: 100-1200mm
Wall Panels Height: 600mm
Corner Panels Width: 100×50/200x200mm
Corner Panels Height: 200/250/600mm
Mini Formwork: 250x250x70/250x200x70200x200x70mm
Inner Angular Formwork: 200x200x200mm
Window /Door Corner Formwork:
200x100x50mm
Round Column: 300/350/400/450x750mm
Adjustable Column Formwork: 750x730x70mm
Weight
14.00KGS/SQM
Loading-Bearing
60KN/SQM
Assembly Efficiency
90SQM per Person per Day
