Sampmax ALTUS Slab Formwork

About Altus

ALTUS is designed for mid-to-high-rise residential and commercial projects where cycle time and cost-per-floor matter most. At approximately 18kg/m², it is one of the lightest aluminum slab systems available — reducing crane dependency, lowering labor fatigue, and keeping installation simple from the first floor to the last.

With a quick-install handle system and compatibility with standard prop equipment, ALTUS minimizes on-site complexity without sacrificing structural performance.

Maximum Coverage. Minimum Effort.

● Maximum panel coverage up to 1800 × 1800 mm (3.24 m² per panel)
Fewer panels to handle, fewer connections to make — every lift covers more ground.
● Lightweight by design
At 18 kg/m², panels are manageable by a two-person team — reducing crane dependency and keeping crews productive across every floor.
● Fast installation sequence
The integrated handle system guides correct panel alignment and connection at every step. Less guesswork, fewer errors, faster setup on repetitive floors.

Fits Your Site. Finishes Clean.

● Works with your existing equipment
ALTUS is compatible with standard prop systems. No proprietary shoring required — lower upfront commitment, simpler site logistics.
● Consistent concrete finish
Aluminum frame with 10mm birch plywood / plastic composite forming face. Tight panel joints deliver a clean, uniform soffit surface — floor after floor.

Technical Data

Formwork Type

Modular slab formwork

Raw Materials

Aluminium/Plywood Panels

Main Sizes

Panels Width:60|90|120|180cm
Panels Length:90|120|180cm
Adjustment panel:55–90×90cm|55–90×180cm

Weight

Panel 180×90cm=27.81kg
Panel 180×120cm=35.64kg
Panel 180×180cm=54.51kg

Relevant standards

Complies with DIN 18202

Corrosion Protection

Powder-coating

Assembly Efficiency

150SQM per Person per Day

Standard Shoring

EN1065 Class B/C props 20 kN | 30 kN
